Overview

Features

• 1400 W continuous program power capacity
• 100 mm (4 in) copper voice coil
• 35 - 1500 Hz response
• 95 dB sensitivity
• Double silicone spider with optimized compliance

Specifications

• Nominal Diameter: 380 mm (15.0 in)
• Nominal Impedance: 8 Ω
• Minimum Impedance: 6.5 Ω
• Nominal Power Handling: 700 W
• Continuous Power Handling: 1400 W
• Sensitivity: 95.0 dB
• Frequency Range: 35 - 1500 Hz
• Voice Coil Diameter: 100 mm (4.0 in)
• Winding Material: Copper
• Former Material: Glass Fibre
• Winding Depth: 21.0 mm (0.83 in)
• Magnetic Gap Depth: 11.0 mm (0.4 in)
• Flux Density: 1.05 T

Mounting and Shipping Info

• Overall Diameter: 393 mm (15.5 in)
• Bolt Circle Diameter: 374 mm (14.72 in)
• Baffle Cutout Diameter: 354.0 mm (13.9 in)
• Depth: 168 mm (6.6 in)
• Flange and Gasket Thickness: 16 mm (0.63 in)
• Air Volume Occupied by Horn: 6.3 dm³ (0.22 ft³)
• Net Weight: 9.8 kg (21.6 lb)
• Shipping Weight: 11.1 kg (24.47 lb)
• Shipping Box: 425x425x224 mm (16.73x16.73x8.82 in)
