PreSonus DIGIMAX LT 8 Channel Microphone Preamp - New Old Stock
Overview
BRAND NEW FACTORY SEALED, NEW OLD STOCK
We unearthed one of these gems from the depths of our warehouse during Spring Cleaning.
No returns if item is opened or installed.Â
The DigiMax LT is essential to the modern digital studio. Eight channels of pristine mic preamplification, inserts on every channel, and an internal power supply set this unit apart from anything on the market. Each channel features our award-winning, high performance, dual servo microphone preamplifiers with 48V phantom power, and -20dB pad. Each channel features a Neutrik™connector that accepts line level or microphone input. DigiMax LT digital synchronization is achieved by offering word clock in and out via BNC connectors. The sample rate can be set on the front panel to 48K, 44.1K, and 32K providing compatibility across multiple platforms.
The DigiMax LT provides TRS inserts on every channel to allow external dynamics processors or equalizers to be placed in the signal chain. The DigiMax LT is the perfect partner for recording systems such as DigiDesign 002™, MOTU828, MOTU 2408™ as well as numerous digital mixers and hard disk recorders.
Features
- ADAT™ LightPipe Output
- Eight Dual Servo Mic Preamps and Line Inputs
- Eight TRS Insert Points
- Linear Internal Power Supply
- 48V Phantom Power on Each Channel
- -20dB Pad on Each Channel
- Adjustable Sample Rates
- BNC I/O for Sync
Specifications
Input
- Number of Channels: Eight
- Input Impedance, XLR Input 1.3K Ohms
- Input Impedance, Line Level Input: 10k Ohms
- Connectors: Neutrik™ Combo
Output
- ADAT™ LightPipe Digital Optical: 24-bit
- Insert (TRS)
- Send (Unbalanced): 51 Ohms
- Return (Unbalanced): 10k Ohms
Panel Controls
- Potentiometer Gain Range (10dB gain at lowest setting): 0dB to +45dB
- Pad: -20 dB
- Phantom Power: +48 V
Meters
- Signal Present LED: -20dBu
- Clip LED: +22dBu
Digital
- Sampling Rates: 32kHz, 44.1kHz, 48kHz
Performance
- Maximum Preamplifier Gain: +55dB
- Headroom: +22dB
- Frequency Response: 20Hz-50kHz
- THD + Noise (Unweighted): <0.009%
- Noise Floor: -94dBu
- Signal to Noise: >98dB
- Analog Dynamic Range: >120dB
- Power Supply Rejection: >98dB
- Amplifier Type: Dual Servo
Physical
- Size: 1U Rack
- Dimensions: 19" W x 1.75" H x 9" D
- Weight: 10 lbs.
- Chassis: Steel
- Panel: Aluminum
Power Supply
- Type: Linear, Internal Input: 100/120/220/240V AC (Factory Configured)
- Power: 80 Watts
Overview
BRAND NEW FACTORY SEALED, NEW OLD STOCK
We unearthed one of these gems from the depths of our warehouse during Spring Cleaning.
No returns if item is opened or installed.Â
The DigiMax LT is essential to the modern digital studio. Eight channels of pristine mic preamplification, inserts on every channel, and an internal power supply set this unit apart from anything on the market. Each channel features our award-winning, high performance, dual servo microphone preamplifiers with 48V phantom power, and -20dB pad. Each channel features a Neutrik™connector that accepts line level or microphone input. DigiMax LT digital synchronization is achieved by offering word clock in and out via BNC connectors. The sample rate can be set on the front panel to 48K, 44.1K, and 32K providing compatibility across multiple platforms.
The DigiMax LT provides TRS inserts on every channel to allow external dynamics processors or equalizers to be placed in the signal chain. The DigiMax LT is the perfect partner for recording systems such as DigiDesign 002™, MOTU828, MOTU 2408™ as well as numerous digital mixers and hard disk recorders.
Features
- ADAT™ LightPipe Output
- Eight Dual Servo Mic Preamps and Line Inputs
- Eight TRS Insert Points
- Linear Internal Power Supply
- 48V Phantom Power on Each Channel
- -20dB Pad on Each Channel
- Adjustable Sample Rates
- BNC I/O for Sync
Specifications
Input
- Number of Channels: Eight
- Input Impedance, XLR Input 1.3K Ohms
- Input Impedance, Line Level Input: 10k Ohms
- Connectors: Neutrik™ Combo
Output
- ADAT™ LightPipe Digital Optical: 24-bit
- Insert (TRS)
- Send (Unbalanced): 51 Ohms
- Return (Unbalanced): 10k Ohms
Panel Controls
- Potentiometer Gain Range (10dB gain at lowest setting): 0dB to +45dB
- Pad: -20 dB
- Phantom Power: +48 V
Meters
- Signal Present LED: -20dBu
- Clip LED: +22dBu
Digital
- Sampling Rates: 32kHz, 44.1kHz, 48kHz
Performance
- Maximum Preamplifier Gain: +55dB
- Headroom: +22dB
- Frequency Response: 20Hz-50kHz
- THD + Noise (Unweighted): <0.009%
- Noise Floor: -94dBu
- Signal to Noise: >98dB
- Analog Dynamic Range: >120dB
- Power Supply Rejection: >98dB
- Amplifier Type: Dual Servo
Physical
- Size: 1U Rack
- Dimensions: 19" W x 1.75" H x 9" D
- Weight: 10 lbs.
- Chassis: Steel
- Panel: Aluminum
Power Supply
- Type: Linear, Internal Input: 100/120/220/240V AC (Factory Configured)
- Power: 80 Watts
Original: $399.00
-65%$399.00
$139.65Description
Overview
BRAND NEW FACTORY SEALED, NEW OLD STOCK
We unearthed one of these gems from the depths of our warehouse during Spring Cleaning.
No returns if item is opened or installed.Â
The DigiMax LT is essential to the modern digital studio. Eight channels of pristine mic preamplification, inserts on every channel, and an internal power supply set this unit apart from anything on the market. Each channel features our award-winning, high performance, dual servo microphone preamplifiers with 48V phantom power, and -20dB pad. Each channel features a Neutrik™connector that accepts line level or microphone input. DigiMax LT digital synchronization is achieved by offering word clock in and out via BNC connectors. The sample rate can be set on the front panel to 48K, 44.1K, and 32K providing compatibility across multiple platforms.
The DigiMax LT provides TRS inserts on every channel to allow external dynamics processors or equalizers to be placed in the signal chain. The DigiMax LT is the perfect partner for recording systems such as DigiDesign 002™, MOTU828, MOTU 2408™ as well as numerous digital mixers and hard disk recorders.
Features
- ADAT™ LightPipe Output
- Eight Dual Servo Mic Preamps and Line Inputs
- Eight TRS Insert Points
- Linear Internal Power Supply
- 48V Phantom Power on Each Channel
- -20dB Pad on Each Channel
- Adjustable Sample Rates
- BNC I/O for Sync
Specifications
Input
- Number of Channels: Eight
- Input Impedance, XLR Input 1.3K Ohms
- Input Impedance, Line Level Input: 10k Ohms
- Connectors: Neutrik™ Combo
Output
- ADAT™ LightPipe Digital Optical: 24-bit
- Insert (TRS)
- Send (Unbalanced): 51 Ohms
- Return (Unbalanced): 10k Ohms
Panel Controls
- Potentiometer Gain Range (10dB gain at lowest setting): 0dB to +45dB
- Pad: -20 dB
- Phantom Power: +48 V
Meters
- Signal Present LED: -20dBu
- Clip LED: +22dBu
Digital
- Sampling Rates: 32kHz, 44.1kHz, 48kHz
Performance
- Maximum Preamplifier Gain: +55dB
- Headroom: +22dB
- Frequency Response: 20Hz-50kHz
- THD + Noise (Unweighted): <0.009%
- Noise Floor: -94dBu
- Signal to Noise: >98dB
- Analog Dynamic Range: >120dB
- Power Supply Rejection: >98dB
- Amplifier Type: Dual Servo
Physical
- Size: 1U Rack
- Dimensions: 19" W x 1.75" H x 9" D
- Weight: 10 lbs.
- Chassis: Steel
- Panel: Aluminum
Power Supply
- Type: Linear, Internal Input: 100/120/220/240V AC (Factory Configured)
- Power: 80 Watts
