Overview

Features

• 500 W continuous program power capacity
• 51 mm (2 in) copper voice coil
• 50 - 4000 Hz response
• 92 dB sensitivity
• Neodymium magnet allows a very light yet powerful motor assembly
• Shorting copper cap for extended HF response
• Ventilated voice coil gap for reduced power compression

Specifications

• Nominal Diameter: 200 mm (8.0 in)
• Nominal Impedance: 8 Ω
• Minimum Impedance: 6.0 Ω
• Nominal Power Handling: 250 W
• Continuous Power Handling: 500 W
• Sensitivity: 92.0 dB
• Frequency Range: 50 - 4000 Hz
• Voice Coil Diameter: 51 mm (2.0 in)
• Winding Material: Copper
• Former Material: Glass Fibre
• Winding Depth: 17.0 mm (0.65 in)
• Magnetic Gap Depth: 8.0 mm (0.31 in)
• Flux Density: 1.15 T

Mounting and Shipping Info

• Overall Diameter: 225 mm (8.8 in)
• Bolt Circle Diameter: 210 mm (8.3 in)
• Baffle Cutout Diameter: 187.0 mm (7.4 in)
• Depth: 90 mm (3.5 in)
• Flange and Gasket Thickness: 11 mm (0.43 in)
• Air Volume Occupied by Horn: 1.1 dm³ (0.04 ft³)
• Net Weight: 1.8 kg (4.0 lb)
• Shipping Weight: 2.25 kg (4.96 lb)
• Shipping Box: 255x255x150 mm (10.04x10.04x5.91 in)
