Overview

Elevate your audio experience with the Taramps T9000 Chipeo, a powerhouse amplifier designed for unparalleled musical performance. Engineered specifically for the 1 Ohm configuration, this amplifier delivers a staggering 9000 WRMS at 12.6 volts, increasing to an impressive 10,000 WRMS at 13.8 volts and peaking at 11,000 WRMS at 14.4 volts. Its wide frequency response of 5Hz to 5kHz covers the full spectrum from sub-bass to mid frequencies, ensuring every note is delivered with exceptional clarity and dynamism. Featuring advanced protection systems and high efficiency, the T9000 Chipeo sets new standards for durability, quality, and sound performance.

Features

• High Power Output: Delivers up to 11,000 WRMS, ensuring powerful and clear audio reproduction.
• Extensive Frequency Response: Ranges from 5Hz to 5kHz, perfect for handling a variety of sound frequencies.
• Efficient Performance: Achieves 79% efficiency at 1 Ohm load.
• Robust Protection System: Protects against short-circuits, over-voltage, under-voltage, and thermal overload.
• Flexible Input Sensitivity: Adjustable from 220mV to 4V RMS to accommodate different audio inputs.

Specifications

• Nominal Power (@12.6VDC):
  • 1 Ohm: 9000W RMS
• Nominal Power (@13.8VDC):
  • 1 Ohm: 10000W RMS
• Nominal Power (@14.4VDC):
  • 1 Ohm: 11000W RMS
• Signal to Noise Ratio: >90dB
• Input Impedance: 10K Ohms
• Minimum Supply Voltage: 9VDC
• Maximum Supply Voltage: 17VDC
• Rest Consumption: 1 Ohm: 3.70A
• Maximum Music Consumption (@12.6VDC):
  • 1 Ohm: 450A
• Maximum Consumption in Sinusoidal Signal:
  • 1 Ohm: 900A
• Dimensions (WxHxD): 8.98" x 2.52" x 17.56" (228 x 64 x 446 mm)
• Weight: 12.79 lb (5.80 Kg)
