Taramps BASS5K 5000 Watt 1 Ohm Bass Mono Car Amplifier
Taramps BASS5000 5000 Watt 1 Ohm Bass Mono Car Amplifier
Overview
The BASS 5k amplifier module is carefully designed with the highest technology, and high performance for automotive sound systems focused on subwoofer and bass response. Its maximum power is 5,000W using 1 channel of 1 OHM, and frequency responses from 8Hz to 250Hz, with customized adjustments according to the size of the trunk, and the frequency of each vehicle. Through the BASS BOOST and the option of choosing the center frequency, this product can offer much more, excessive displacement control, through SUBSONIC FILTER, volume control and LOW PASS, to hear your bass in the right measure.
|
OPERATION CLASS |
Class D |
|
NUMBER OF CHANNELS |
1 |
|
MAXIMUM POWER |
@ 14.4 VDC - 1 OHM: 5000W RMS @ 14.4 VDC - 2 OHMS: 3200W RMS |
|
INPUT SENSITIVITY |
220mV |
|
SIGNAL TO NOISE RATIO |
>95dB |
|
FREQUENCY RESPONSE |
8Hz ~ 250Hz (-3dB) |
|
CROSSOVER HIGH PASS (HPF) |
8Hz ~ 30Hz (-12dB/8ª) Variable |
|
CROSSOVER LOW PASS (LPF) |
60Hz ~ 250Hz (-12dB/8ª) Variable |
|
BASS BOOST |
35Hz ~ 60Hz (0 ~10dB) |
|
EFFICIENCY |
83% |
|
INPUT IMPEDANCE |
22K Ohms |
|
OUTPUT IMPEDANCE |
1 Ohm |
|
PROTECTION SYSTEM |
Short-Circuit to Output, Short on output compared to GND, Low impedance at output, High/Low supply voltage and Thermal protection |
|
MIN. SUPPLY VOLTAGE |
9VDC |
|
MAXIMUM POWER SUPPLY VOLTAGE |
17VDC |
|
CONSUMPTION AT REST |
1.20A |
|
MAXIMUM MUSIC CONSUMPTION |
209A |
|
MAXIMUM CONSUMPTION IN SINUSOIDAL SIGNAL |
418A |
|
DIMENSIONS (H X W X D) MM |
9.41" x 2.87" x 12.87" |
|
WEIGHT |
11lb |
Taramps BASS5000 5000 Watt 1 Ohm Bass Mono Car Amplifier
Overview
The BASS 5k amplifier module is carefully designed with the highest technology, and high performance for automotive sound systems focused on subwoofer and bass response. Its maximum power is 5,000W using 1 channel of 1 OHM, and frequency responses from 8Hz to 250Hz, with customized adjustments according to the size of the trunk, and the frequency of each vehicle. Through the BASS BOOST and the option of choosing the center frequency, this product can offer much more, excessive displacement control, through SUBSONIC FILTER, volume control and LOW PASS, to hear your bass in the right measure.
|
OPERATION CLASS |
Class D |
|
NUMBER OF CHANNELS |
1 |
|
MAXIMUM POWER |
@ 14.4 VDC - 1 OHM: 5000W RMS @ 14.4 VDC - 2 OHMS: 3200W RMS |
|
INPUT SENSITIVITY |
220mV |
|
SIGNAL TO NOISE RATIO |
>95dB |
|
FREQUENCY RESPONSE |
8Hz ~ 250Hz (-3dB) |
|
CROSSOVER HIGH PASS (HPF) |
8Hz ~ 30Hz (-12dB/8ª) Variable |
|
CROSSOVER LOW PASS (LPF) |
60Hz ~ 250Hz (-12dB/8ª) Variable |
|
BASS BOOST |
35Hz ~ 60Hz (0 ~10dB) |
|
EFFICIENCY |
83% |
|
INPUT IMPEDANCE |
22K Ohms |
|
OUTPUT IMPEDANCE |
1 Ohm |
|
PROTECTION SYSTEM |
Short-Circuit to Output, Short on output compared to GND, Low impedance at output, High/Low supply voltage and Thermal protection |
|
MIN. SUPPLY VOLTAGE |
9VDC |
|
MAXIMUM POWER SUPPLY VOLTAGE |
17VDC |
|
CONSUMPTION AT REST |
1.20A |
|
MAXIMUM MUSIC CONSUMPTION |
209A |
|
MAXIMUM CONSUMPTION IN SINUSOIDAL SIGNAL |
418A |
|
DIMENSIONS (H X W X D) MM |
9.41" x 2.87" x 12.87" |
|
WEIGHT |
11lb |
Description
Taramps BASS5000 5000 Watt 1 Ohm Bass Mono Car Amplifier
Overview
The BASS 5k amplifier module is carefully designed with the highest technology, and high performance for automotive sound systems focused on subwoofer and bass response. Its maximum power is 5,000W using 1 channel of 1 OHM, and frequency responses from 8Hz to 250Hz, with customized adjustments according to the size of the trunk, and the frequency of each vehicle. Through the BASS BOOST and the option of choosing the center frequency, this product can offer much more, excessive displacement control, through SUBSONIC FILTER, volume control and LOW PASS, to hear your bass in the right measure.
|
OPERATION CLASS |
Class D |
|
NUMBER OF CHANNELS |
1 |
|
MAXIMUM POWER |
@ 14.4 VDC - 1 OHM: 5000W RMS @ 14.4 VDC - 2 OHMS: 3200W RMS |
|
INPUT SENSITIVITY |
220mV |
|
SIGNAL TO NOISE RATIO |
>95dB |
|
FREQUENCY RESPONSE |
8Hz ~ 250Hz (-3dB) |
|
CROSSOVER HIGH PASS (HPF) |
8Hz ~ 30Hz (-12dB/8ª) Variable |
|
CROSSOVER LOW PASS (LPF) |
60Hz ~ 250Hz (-12dB/8ª) Variable |
|
BASS BOOST |
35Hz ~ 60Hz (0 ~10dB) |
|
EFFICIENCY |
83% |
|
INPUT IMPEDANCE |
22K Ohms |
|
OUTPUT IMPEDANCE |
1 Ohm |
|
PROTECTION SYSTEM |
Short-Circuit to Output, Short on output compared to GND, Low impedance at output, High/Low supply voltage and Thermal protection |
|
MIN. SUPPLY VOLTAGE |
9VDC |
|
MAXIMUM POWER SUPPLY VOLTAGE |
17VDC |
|
CONSUMPTION AT REST |
1.20A |
|
MAXIMUM MUSIC CONSUMPTION |
209A |
|
MAXIMUM CONSUMPTION IN SINUSOIDAL SIGNAL |
418A |
|
DIMENSIONS (H X W X D) MM |
9.41" x 2.87" x 12.87" |
|
WEIGHT |
11lb |
