Taramps 1 Channel 200 Watts RMS 4 Ohm Car Audio Amplifier - TL1500
Overview
The TL 1500 amplifier module is carefully developed with state-of-the-art technology, offering high efficiency and performance for automotive audio systems. Classified as Stereo, it has two 95 watts RMS stereo channels running at a 2-ohms impedance, with a maximum power of 190 watts RMS, and one 200 watts RMS channel destinated to subwoofers, running at a 4-ohms impedance, with a maximum power of 200 watts RMS. It is FULL-RANGE, operating on all frequencies in the right measure.
Specs:
|
OPERATION CLASS |
Class D |
|
NUMBER OF CHANNELS |
3 |
|
MAXIMUM POWER |
@ 13.8 VDC - 2 OHMS 2 x 95W RMS (STEREO) @ 13.8 VDC - 4 OHMS 1 x 200W RMS (SUB) |
|
INPUT SENSITIVITY |
Input RCA = 320mV Wire Input = 6V |
|
SIGNAL TO NOISE RATIO |
>90dB |
|
FREQUENCY RESPONSE |
Sub Output: 15Hz to 90Hz and its active frequency cut (12dB/8ª) Stereo Output L/R: 90Hz to 30kHz and its active frequency cut (12dB/8ª) |
|
BASS BOOST |
Adjustable 0 to 10dB @ 50Hz |
|
EFFICIENCY |
90% |
|
INPUT IMPEDANCE |
10K OHMS (RCA) 1K OHMS (WIRE) |
|
PROTECTION SYSTEM |
Thermal and Output Short |
|
MIN. SUPPLY VOLTAGE |
9VDC |
|
MAXIMUM POWER SUPPLY VOLTAGE |
16VDC |
|
CONSUMPTION AT REST |
0,75A |
|
MAXIMUM MUSIC CONSUMPTION |
17,5A |
|
MAXIMUM CONSUMPTION IN SINUSOIDAL SIGNAL |
35A |
|
DIMENSIONS (H X W X D) |
5.43" x 1.93" x 4.76" |
|
WEIGHT |
1.32lb |
