Taramps 1 Channel 3000 Watts RMS Car Audio Amplifier with Bass Boost - SMART3
Overview
SMART 3, the pioneer of a line developed with the highest technology and performance for automotive sound systems. The biggest differential is its multi-impedance function (Power Control System), which allows the work of 1 to 2 Ohms in the same product. It is a mono amplifier, with power of 3,000 Watts RMS, which has protection against short circuit at the output, high / low voltage and thermal protection. Your logo tells you what power is running during the amplifier’s operation, providing greater reliability for your system. It is an exclusive TARAMPS product and with the best cost-benefit ratio in the automotive sound industry.
SPECIFICATIONS
|
OPERATION CLASS |
Class D |
|
NUMBER OF CHANNELS |
1 |
|
MAXIMUM POWER |
@ 12.6 VDC - 1 Ohm: 3000 Watts RMS @ 12.6 VDC - 2 Ohms: 3000 Watts RMS @ 12.6 VDC - 4 Ohms: 2000 Watts RMS |
|
INPUT SENSITIVITY |
0.22V ~ 4V |
|
SIGNAL TO NOISE RATIO |
>90dB |
|
FREQUENCY RESPONSE |
10Hz ~ 10KHz (-3dB) |
|
CROSSOVER HIGH PASS (HPF) |
10Hz ~ 90Hz (-12dB/8ª) Variable |
|
CROSSOVER LOW PASS (LPF) |
90Hz ~ 10KHz (-12dB/8ª) Variable |
|
BASS BOOST |
Freq.: 35Hz ~ 55Hz / Boost: 0 ~ +10dB |
|
EFFICIENCY |
79% |
|
INPUT IMPEDANCE |
10K Ohms |
|
PROTECTION SYSTEM |
Output short circuit, low / high voltage protection and thermal protection |
|
MIN. SUPPLY VOLTAGE |
9 VDC |
|
MAXIMUM POWER SUPPLY VOLTAGE |
16 VDC |
|
CONSUMPTION AT REST |
2.40A |
|
MAXIMUM MUSIC CONSUMPTION |
150A |
|
MAXIMUM CONSUMPTION IN SINUSOIDAL SIGNAL |
300A |
|
DIMENSIONS (H X W X D) |
8.98" x 2.76" x 9.37" |
|
WEIGHT |
5.72lb |
