Overview

This is the VERSION 2 model of the Taramps MD8000.2. Taramps made a running change to this amplifier without updating the SKU, leading to differences in design and specifications. Please review the updated specs and images before purchasing.

The Taramps MD8000.2 V2 is a high-powered Class D monoblock amplifier designed for serious audio enthusiasts. Delivering 8000 watts of power, this amp provides exceptional sound clarity and efficiency while maintaining compact dimensions for easy installation. It features a variable high-pass and low-pass crossover, a signal-to-noise ratio of >90dB, and an input sensitivity range of 0.22V to 4V, ensuring a precise and adaptable setup for different systems.

Equipped with a comprehensive protection system, the MD8000.2 V2 guards against short circuits, low impedance, and high/low voltage fluctuations, ensuring long-term reliability. With a minimum supply voltage of 9.5VDC and a maximum of 17VDC, this amplifier is built to handle demanding audio applications with stability and power.

Features:

• Version 2 Model – Updated design and specifications
• 8000 Watts of Power – Delivers massive output for high-performance systems
• Compact Dimensions – 8.98" x 2.76" x 17.5" for easy installation
• Class D Monoblock Amplifier – Efficient power conversion with minimal heat generation
• Variable High-Pass & Low-Pass Crossover – Allows precise frequency control
• Wide Input Sensitivity Range (0.22V ~ 4V) – Compatible with various setups
• Signal-to-Noise Ratio >90dB – Ensures clean, distortion-free sound
• Output Impedance: Supports 1 or 2 Ohms
• Advanced Protection System – Protects against short circuits, over/under voltage, and overheating
• New Open Box Condition – Fully functional with minimal handling

Specifications:

• Operation Class: D
• Number of Channels: 1
• Input Sensitivity: 0.22V ~ 4V
• Signal-to-Noise Ratio: >90dB
• Frequency Response: 10Hz ~ 10KHz (-3dB)
• Crossover High Pass (HPF): 10Hz ~ 90Hz (-12dB/8ª) Variable
• Crossover Low Pass (LPF): 90Hz ~ 10KHz (-12dB/8ª) Variable
• Input Impedance: 10K Ohms
• Output Impedance: 1 or 2 Ohms
• Protection System: Short-Circuit to Output, Short on output compared to GND, Low impedance at output, High/Low supply voltage, Thermal protection
• Minimum Supply Voltage: 9.5VDC
• Maximum Supply Voltage: 17VDC
• Consumption at Rest: 2.90A
• Maximum Music Consumption: 387A
• Maximum Consumption in Sinusoidal Signal: 774A
• Weight: 12.3lb (5.60kg)
